6 in 1 Logic Gate Apparatus Manufacturer,Supplier and Exporter in India
Product Code : SCL-EAE-11327
The apparatus combines AND, OR, NOT, NAND, NOR and XOR gate experiments on one educational platform. Each gate processes binary input conditions and produces an output according to its Boolean function. Students can compare the observed output with the expected truth-table value.
The integrated format reduces the need to assemble every gate circuit separately. Clearly arranged gate sections support demonstrations, individual practical work and comparison between basic and universal gates. The operating voltage, IC family, input controls, output indicators, enclosure material and dimensions must be confirmed before ordering.
Key Features
Six logic functions: Combines AND, OR, NOT, NAND, NOR and XOR experiments in one apparatus.
Truth-table verification: Allows students to test binary input combinations and record the resulting outputs.
Boolean logic learning: Connects logic symbols, expressions and truth tables with practical observations.
Input-output comparison: Makes the effect of each input condition directly observable.
Universal-gate study: Supports introductory discussion of NAND and NOR as universal logic gates.
Integrated training format: Keeps multiple experiments organised on one laboratory platform.
Hands-on STEM use: Suitable for supervised digital electronics demonstrations and student practicals.
Technical Specifications
|
6 in 1 Logic Gate Apparatus technical information |
|
|
Specification |
Detail |
|
Product name |
6 in 1 Logic Gate Apparatus |
|
Brand |
Lab Exports |
|
Equipment category |
Digital electronics and logic-gate trainer |
|
Number of gate functions |
Six |
|
Logic gates |
AND, OR, NOT, NAND, NOR and XOR |
|
Primary experiment |
Verification of logic-gate truth tables |
|
Logic states |
Binary 0 and binary 1 |
What's Included in the Kit
One 6 in 1 Logic Gate Apparatus.
Connecting leads, power arrangement and experiment manual only when listed in the accepted quotation.
Applications and Uses
Verifying AND, OR and NOT gate truth tables.
Verifying NAND, NOR and XOR gate truth tables.
Studying binary input and output states.
Comparing basic gates with universal gates.
Relating logic symbols to Boolean expressions.
Introducing combinational digital circuits.
Supporting digital electronics, computer science and STEM practicals.
Extending experiments with an Analog & Digital IC Trainer.
How to Use the 6 in 1 Logic Gate Apparatus
Identify the required logic-gate section and its input and output points.
Confirm the approved power requirement before connection.
Keep the apparatus switched off while attaching leads.
Select the first binary input combination.
Switch on the apparatus and observe the output indication.
Record the output as logic 0 or logic 1.
Repeat the procedure for every possible input combination.
Compare the recorded values with the theoretical truth table.
Switch off the apparatus before changing circuit connections.
Safety note: Use only the confirmed supply voltage. Do not short output terminals, alter connections while energised or apply an external voltage to the logic inputs.
Care and Maintenance
Keep the panel, switches, indicators and terminals clean and dry.
Inspect connecting leads and terminal insulation before each session.
Use controls gently and avoid forcing plugs into terminals.
Store the apparatus disconnected in a dry, dust-controlled cabinet.
Why Choose Lab Exports
Lab Exports manufactures and exports scientific instruments, laboratory experiment setups, science kits, mathematics kits, didactic models and STEM equipment. Its physics range includes digital electronics trainers, circuit apparatus and electrical measurement equipment. The company supplies schools, colleges, universities and vocational institutions in domestic and international markets. Buyers can confirm the IC family, supply rating and included accessories before production and dispatch.
Frequently Asked Questions
What is a 6 in 1 Logic Gate Apparatus used for?
It is used to demonstrate six digital logic functions and verify their truth tables using binary inputs and outputs.
Which logic gates are included?
The apparatus covers AND, OR, NOT, NAND, NOR and XOR logic operations.
What is a logic-gate truth table?
A truth table lists the output produced by a logic gate for every possible binary input combination.
Why are NAND and NOR called universal gates?
NAND or NOR gates can be combined to construct the functions of other standard logic gates.
Can students perform the experiments individually?
Yes. The integrated format supports supervised individual or small-group practical work.
Is a power supply included?
The complete supply scope was not confirmed. Buyers should verify the power arrangement, leads and experiment manual in the quotation.
Request confirmation of the operating voltage, IC family and included accessories, or explore the complete Electrical and Electronics Laboratory Equipment range and related Digital IC Trainer.
